zemic load cell parallel type L6D-C3-10KG-2B single point construction with capacity 3kg-50kg

Brand Name : kaw

Model Number : L6D-C3-20KG-3B

Certification : ROSH

Place of Origin : CHINA

MOQ : 1pcs

Price : USD20~30/PCS

Payment Terms : Western Union, MoneyGram, T/T, L/C

Supply Ability : 1000PCS/Month

Packaging Details : paper cartons, 16pcs/carton

name : zemic load cell

accurracy : 0.5%

material : steel

capacity : 3-50kg

load direction : compression

application : pricing scales, bench scales

Contact Now

zemic load cell parallel type L6D-C3-10KG-2B single point construction with capacity 3kg-50kg

Features:

Aluminium-alloy IP65 single point load cell.
Colourless anodized
Suitable for pricing scales, bench scales, etc.
Maximum platform size: 250 x 350 mm

Available models

zemic load cell parallel type L6D-C3-10KG-2B single point construction with capacity 3kg-50kg

Capacity	Accuracy	Full article description

2.5kg	C3 Excluded from OIML	L6D-C3-2.5kg-0.40B

3kg	C3/C4/C5	L6D-C3/C4/C5-3kg-0.40B

5kg	C3/C4/C5	L6D-C3/C4/C5-5kg-0.40B

6kg	C3/C4/C5	L6D-C3/C4/C5-6kg-0.40B

8kg	C3/C4/C5	L6D-C3/C4/C5-8kg-0.40B

10kg	C3/C4/C5	L6D-C3/C4/C5-10kg-0.40B

15kg	C3/C4/C5	L6D-C3/C4/C5-15kg-0.40B

20kg	C3/C4/C5	L6D-C3/C4/C5-20kg-0.40B

30kg	C3/C4/C5	L6D-C3/C4/C5-30kg-0.40B

35kg	C3/C4/C5	L6D-C3/C4/C5-35kg-0.40B

40kg	C3/C4/C5	L6D-C3/C4/C5-40kg-0.40B

50kg	C3/C4/C5	L6D-C3/C4/C5-50kg-0.40B

Detailed specifications L6D

zemic load cell parallel type L6D-C3-10KG-2B single point construction with capacity 3kg-50kg

Accuracy class		C3		OIML R60 C3		OIML R60 C4	OIML R60 C5

Output sensitivity ( = FS )	mV/V	1.8 ± 0.2			2.0 ± 0.2

Maximum capacity ( E_max )	kg	2.5		3, 5, 6, 8, 10, 15, 20, 30, 35, 40, 50
Max.number of load cell intervals	ⁿLC	3000		3000		4000	5000
Ratio of min. LC verification interval	^{Y = E}max ^{/ v}min	7000		10000		15000	20000
Combined Error	%FS		≤± 0.0230			≤± 0.0175	≤± 0.0140

Minimum dead load	Of E_max		0%
Safe overload	^{of E}max		150 %
Ultimate overload	^{of E}max		300 %
Zero balance	of FS		< ± 2.0 %

Excitation, recommended voltage	V		5 ~ 12

Excitation maximum	V				18

Input resistance	Ω		409 ± 6

Output resistance	Ω		350 ± 3

Insulation resistance	MΩ			≥5000 ( at 50VDC )

Compensated temperature	°C			-10…+40

Operating temperature	°C			-35…+65

Storage temperature	°C			-40…+70

Element material				Aluminium

Ingress Protection (acc. to EN 60529)				IP65

Recommended torque on fixation	Nm		< 30kg: 6			>30kg: 10

Wiring

zemic load cell parallel type L6D-C3-10KG-2B single point construction with capacity 3kg-50kg

Wiring:

Shielded, 4 conductor cable.

Cable diameter: Ø3.8mm.

Standard cable length: 0.40m

Shield not connected to element.

Cable jacket in PVC.

zemic load cell parallel type L6D-C3-10KG-2B single point construction with capacity 3kg-50kg

L6D-C3-2.5KG-0.4B
L6D-C3-3KG-0.4B
L6D-C3-5KG-0.4B
L6D-C3-6KG-0.4B
L6D-C3-8KG-0.4B
L6D-C3-10KG-0.4B
L6D-C3-3KG-3B
L6D-C3-5KG-3B
L6D-C3-6KG-3B
L6D-C3-8KG-3B
L6D-C3-10KG-2B
L6D-C3-15KG-3B
L6D-C3-20KG-3B
L6D-C3-30KG-2B
L6D-C3-35KG-3B
L6D-C3-40KG-2B
L6D-C3-50KG-3B
L6D-C3-2.5KG
L6D-3KG
L6D-5KG
L6D-6KG
L6D-8KG
L6D-10KG
L6D-15KG
L6D-20KG
L6D-30KG
L6D-35KG
L6D-40KG
L6D-50KG

L6D21-C3-3KG-3B
L6D21-C3-6KG-3B
L6D21-C3-10KG-3B
L6D21-C3-15KG-3B
L6D21-C3-20KG-3B
L6D21-C3-30KG-3B
L6D21-C3-40KG-3B
L6D21-C3-50KG-3B
L6D-C3-2.5KG-0.4B
L6D-C3-2.5KG-0.4B-R1
L6D-C3-3KG-0.4B-R1
L6D-C3-5KG-0.4B-R1
L6D-C3-6KG-0.4B-R1
L6D-C3-8KG-0.4B-R1
L6D-C3-10KG-0.4B-R1
L6D-C3-15KG-0.4B-R1
L6D-C3-20KG-0.4B-R1
L6D-C3-30KG-0.4B-R1
L6D-C3-35KG-0.4B-R1
L6D-C3-40KG-0.4B-R1
L6D-C3-50KG-0.4B-R1
