| Introduction of XK3190-A1+P indicators |
| Weighing indicator XK3190-A1+P adpots A/D conversion technology, original from model XK3190-A1+, with built in printer |
| widely applied in eletronic floor scale, platform scale |
| applied in static weighing system equipped with 1~4 load cells |
| Features of XK3190-A1+P indicators: |
| Zero range setup (auto/manual) |
| Date and time display(note: no power no save) |
| Save accumulation result manually |
| Weighing data save protection in case of power off |
| able to print weighing records auto/manual |
| Standard RS232C communication interface with selectable baud rate and communication method |
| Standard scoreboad interface serial sending signal by current loop, transmission distance: ≤50meters |
| With built-in 16 row micro printer |
| Technical Parameter of XK3190-A1+P indicators: |
| A/D conversion method: Double integral |
| A/D conversion speed:≥5times/sec/ |
| Input signal range: 1mV~24mV |
| Input sensitiity: ≥1μV |
| Load cell excitation: DC12V |
| Max. connection number of load cell: 4 at 350ohm |
| Load cell connection mode: 4 wire |
| Verified counts: 3000 |
| Division: 1/2/3/10/20/50/100 optional |
| Display: 7bits LED, 7 status indicators |
| Display Range: -099990~99990(d＝10) |
| Clock: software clock, clock data lose on power off |
| Scoreboard interface(standard) |
| Serial sending sigal by current loop with baud rate 600, |
| Transmission distance:≤50meters |
| Communication interface(RS232C standard) |
| Serial communication interface, with selectable baud rate by continous sending method or on command method |
| Transmission distance: RS232C ≤30meters |
| Baud rate: 600/1200/2400/4800/9600 |
| Transmission distance:¡Ü2000 meters |
| Printer interface |
| Pinter model LQ-300K,KX-P1131,KX-P1121 |
| Serial communication interface |
| Standard interface: RS232C(RS422/RS485 optional) |
| Baud rate:600/1200/2400/4800/9600 |
| Transmission distance: RS232C¡Ü30 meters:RS422/RS485¡Ü1200 meters |
| Power supply of XK3190-A1+P indicators |
| AC 187~242V; 49~51Hz |
